Class 10.9 Metric Blue Steel Bolts
Class 10.9, High Visibility, DIN 933
| Class 10.9 Blue Steel Bolts Fully Threaded | ||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| Bolt-1501 | M6 x 1 | 16mm | 10mm | 4mm | 50 | $23.03 |
| Bolt-1502 | M6 x 1 | 20mm | 10mm | 4mm | 50 | $30.64 |
| Bolt-1503 | M6 x 1 | 25mm | 10mm | 4mm | 50 | $28.98 |
| Bolt-1508 | M8 x 1.25 | 16mm | 13mm | 5.3mm | 25 | $25.70 |
| Bolt-1509 | M8 x 1.25 | 20mm | 13mm | 5.3mm | 25 | $27.93 |
| Bolt-1510 | M8 x 1.25 | 25mm | 13mm | 5.3mm | 25 | $25.89 |
| Bolt-1511 | M8 x 1.25 | 30mm | 13mm | 5.3mm | 25 | $33.83 |
| Bolt-1519 | M10 x 1.5 | 80mm | 13mm | 5.3mm | 20 | $39.56 |
| Bolt-1518 | M10 x 1.5 | 20mm | 17mm | 6.4mm | 20 | $39.56 |
| Bolt-1520 | M10 x 1.5 | 25mm | 17mm | 6.4mm | 20 | $42.04 |
| Bolt-1521 | M10 x 1.5 | 30mm | 17mm | 6.4mm | 20 | $45.10 |
| Bolt-1522 | M10 x 1.5 | 35mm | 17mm | 6.4mm | 10 | $24.76 |
| Bolt-1532 | M12 x 1.75 | 20mm | 19mm | 7.5mm | 10 | $27.55 |
| Bolt-1533 | M12 x 1.75 | 25mm | 19mm | 7.5mm | 10 | $29.44 |
| Bolt-1534 | M12 x 1.75 | 30mm | 19mm | 7.5mm | 10 | $32.50 |
| Bolt-1535 | M12 x 1.75 | 35mm | 19mm | 7.5mm | 10 | $25.07 |
| Bolt-1536 | M12 x 1.75 | 40mm | 19mm | 7.5mm | 10 | $41.49 |
| Bolt-1537 | M12 x 1.75 | 45mm | 19mm | 7.5mm | 10 | $42.12 |
| Bolt-1546 | M16 x 2 | 30mm | 24mm | 10mm | 5 | $36.60 |
| Bolt-1547 | M16 x 2 | 35mm | 24mm | 10mm | 5 | $37.04 |
| Bolt-1548 | M16 x 2 | 40mm | 24mm | 10mm | 5 | $33.05 |
| Bolt-1549 | M16 x 2 | 45mm | 24mm | 10mm | 5 | $41.98 |
| Bolt-1550 | M16 x 2 | 50mm | 24mm | 10mm | 5 | $21.86 |
| Bolt-1557 | M20 x 2.5 | 60mm | 30mm | 12.5mm | 5 | $74.00 |
| Class 10.9 Blue Steel Bolts Partially Threaded | |||||||
| Part # | Thread Length | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|
| Bolt-1504 | 18 to 23 | M6 x 1 | 30mm | 10mm | 4mm | 50 | $33.41 |
| Bolt-1505 | 18 to 23 | M6 x 1 | 35mm | 10mm | 4mm | 25 | $23.12 |
| Bolt-1506 | 18 to 23 | M6 x 1 | 40mm | 10mm | 4mm | 25 | $25.68 |
| Bolt-1507 | 18 to 23 | M6 x 1 | 50mm | 10mm | 4mm | 25 | $25.09 |
| Bolt-1512 | 22 to 29 | M8 x 1.25 | 35mm | 13mm | 5.3mm | 20 | $37.25 |
| Bolt-1513 | 22 to 29 | M8 x 1.25 | 40mm | 13mm | 5.3mm | 20 | $38.47 |
| Bolt-1514 | 22 to 29 | M8 x 1.25 | 50mm | 13mm | 5.3mm | 20 | $38.89 |
| Bolt-1515 | 22 to 29 | M8 x 1.25 | 60mm | 13mm | 5.3mm | 10 | $24.92 |
| Bolt-1516 | 22 to 29 | M8 x 1.25 | 70mm | 13mm | 5.3mm | 10 | $27.42 |
| Bolt-1517 | 22 to 29 | M8 x 1.25 | 80mm | 13mm | 5.3mm | 10 | $30.76 |
| Bolt-1523 | 26 to 34 | M10 x 1.5 | 40mm | 17mm | 6.4mm | 10 | $27.78 |
| Bolt-1524 | 26 to 34 | M10 x 1.5 | 50mm | 17mm | 6.4mm | 10 | $16.63 |
| Bolt-1525 | 26 to 34 | M10 x 1.5 | 60mm | 17mm | 6.4mm | 10 | $30.19 |
| Bolt-1526 | 26 to 34 | M10 x 1.5 | 70mm | 17mm | 6.4mm | 10 | $44.22 |
| Bolt-1527 | 26 to 34 | M10 x 1.5 | 75mm | 17mm | 6.4mm | 5 | $22.53 |
| Bolt-1528 | 26 to 34 | M10 x 1.5 | 80mm | 17mm | 6.4mm | 5 | $24.88 |
| Bolt-1529 | 26 to 34 | M10 x 1.5 | 90mm | 17mm | 6.4mm | 5 | $28.58 |
| Bolt-1530 | 26 to 34 | M10 x 1.5 | 100mm | 17mm | 6.4mm | 5 | $29.59 |
| Bolt-1531 | 26 to 34 | M10 x 1.5 | 120mm | 17mm | 6.4mm | 5 | $45.13 |
| Bolt-1538 | 30 to 39 | M12 x 1.75 | 50mm | 19mm | 7.5mm | 5 | $24.36 |
| Bolt-1539 | 30 to 39 | M12 x 1.75 | 60mm | 19mm | 7.5mm | 5 | $28.07 |
| Bolt-1540 | 30 to 39 | M12 x 1.75 | 70mm | 19mm | 7.5mm | 5 | $31.66 |
| Bolt-1541 | 30 to 39 | M12 x 1.75 | 80mm | 19mm | 7.5mm | 5 | $17.76 |
| Bolt-1542 | 30 to 39 | M12 x 1.75 | 90mm | 19mm | 7.5mm | 5 | $37.36 |
| Bolt-1543 | 30 to 39 | M12 x 1.75 | 100mm | 19mm | 7.5mm | 5 | $20.56 |
| Bolt-1544 | 30 to 39 | M12 x 1.75 | 110mm | 19mm | 7.5mm | 5 | $39.96 |
| Bolt-1545 | 30 to 39 | M12 x 1.75 | 120mm | 19mm | 7.5mm | 5 | $49.32 |
| Bolt-1551 | 38 to 48 | M16 x 2 | 60mm | 24mm | 10mm | 5 | $22.26 |
| Bolt-1552 | 38 to 48 | M16 x 2 | 70mm | 24mm | 10mm | 5 | $32.50 |
| Bolt-1553 | 38 to 48 | M16 x 2 | 80mm | 24mm | 10mm | 5 | $66.65 |
| Bolt-1554 | 38 to 48 | M16 x 2 | 100mm | 24mm | 10mm | 5 | $22.95 |
| Bolt-1555 | 38 to 48 | M16 x 2 | 120mm | 24mm | 10mm | 5 | $93.11 |
| Bolt-1556 | 38 to 48 | M16 x 2 | 140mm | 24mm | 10mm | 5 | $91.33 |
| Bolt-1558 | 46 to 59 | M20 x 2.5 | 70mm | 30mm | 12.5mm | 1 | $12.18 |
| Bolt-1559 | 46 to 59 | M20 x 2.5 | 80mm | 30mm | 12.5mm | 5 | $93.85 |
| Bolt-1560 | 46 to 59 | M20 x 2.5 | 90mm | 30mm | 12.5mm | 5 | $52.31 |
| Bolt-1561 | 46 to 59 | M20 x 2.5 | 100mm | 30mm | 12.5mm | 1 | $22.82 |
| Bolt-1562 | 46 to 59 | M20 x 2.5 | 120mm | 30mm | 12.5mm | 1 | $26.41 |
| Bolt-1563 | 46 to 59 | M20 x 2.5 | 140mm | 30mm | 12.5mm | 1 | $30.53 |
| Bolt-1564 | 54 to 69 | M24 x 3 | 80mm | 36mm | 15mm | 1 | $31.64 |
| Bolt-1565 | 54 to 69 | M24 x 3 | 90mm | 36mm | 15mm | 1 | $34.60 |
| Bolt-1566 | 54 to 69 | M24 x 3 | 100mm | 36mm | 15mm | 1 | $45.27 |
| Bolt-1567 | 54 to 69 | M24 x 3 | 120mm | 36mm | 15mm | 1 | $41.41 |
| Bolt-1568 | 54 to 69 | M24 x 3 | 140mm | 36mm | 15mm | 1 | $49.89 |
| Bolt-1569 | 54 to 69 | M24 x 3 | 150mm | 36mm | 15mm | 1 | $51.11 |
