Grade 5 Plated Steel Carriage Bolts

Rust Resistant. SAE J429. C25 Rockwell. 120K PSI Tensile strength. Partial Threads.

Grade 5 Plated Carriage Bolts

Thread Size (in.)	Length (in.)	Part #	Pkg. Qty.	Pkg. Price
1/4-20	0.750	DCR-804	100	$27.88
1/4-20	1.000	DCR-805	50	$24.60
1/4-20	1.250	DCR-806	100	$25.66
1/4-20	1.500	DCR-807	100	$33.17
1/4-20	2.000	DCR-808	100	$31.77
1/4-20	2.500	DCR-809	25	$24.21
5/16-18	0.750	DCR-810	100	$39.56
5/16-18	1.000	DCR-811	100	$47.95
5/16-18	1.250	DCR-812	100	$48.23
5/16-18	1.500	DCR-813	25	$27.04
5/16-18	2.000	DCR-814	100	$40.22
5/16-18	2.500	DCR-815	50	$33.00
5/16-18	3.000	DCR-816	25	$53.07
5/16-18	4.500	DCR-875	50	$51.94
3/8-16	0.750	DCR-817	100	$55.06
3/8-16	1.000	DCR-818	100	$43.19
3/8-16	1.250	DCR-819	25	$30.67
3/8-16	1.500	DCR-820	25	$37.16
3/8-16	1.750	DCR-821	25	$33.00
3/8-16	2.000	DCR-822	25	$37.04
3/8-16	2.250	DCR-823	25	$75.46
3/8-16	2.500	DCR-824	50	$34.03
3/8-16	3.000	DCR-825	25	$59.49
3/8-16	3.875	DCR-826	10	$22.34
3/8-16	4.000	DCR-827	10	$24.82
3/8-16	10.000	DCR-901	10	$34.25
1/2-13	1.000	DCR-828	10	$28.78
1/2-13	1.250	DCR-829	10	$25.13
1/2-13	1.500	DCR-830	10	$25.66
1/2-13	1.750	DCR-831	10	$26.55
1/2-13	2.000	DCR-832	10	$31.26
1/2-13	2.500	DCR-833	10	$32.94
1/2-13	3.000	DCR-834	10	$37.80
1/2-13	3.875	DCR-835	10	$81.59
1/2-13	4.000	DCR-836	10	$49.40
1/2-13	4.500	DCR-837	10	$51.29
1/2-13	5.000	DCR-838	5	$27.90
5/8-11	2.000	DCR-839	10	$16.71
5/8-11	2.500	DCR-840	5	$27.43
5/8-11	3.000	DCR-841	5	$31.71
5/8-11	3.875	DCR-842	5	$35.14
5/8-11	4.000	DCR-843	5	$39.34
