Flanged Lock Nuts
Insert has a maximum temperature of 250°F
| Grade G Zinc Yellow Chromate Flanged Hex Nuts | ||||||||
| Part # | Thread Size | Width | Height | Flange Dia | Flange Thickness | Pkg. Qty. | Pkg. Price | |
|---|---|---|---|---|---|---|---|---|
| DHN-1541 | 1/4"-20 | 7/16" | 19/64" | 0.56" | 0.04" | 200 | $26.36 | |
| DHN-1542 | 5/16"-18 | 1/2" | 11/32" | 0.68" | 0.05" | 100 | $26.36 | |
| DHN-1543 | 3/8"-16 | 9/16" | 13/32" | 0.81" | 0.06" | 100 | $26.36 | |
| DHN-1544 | 1/2"-13 | 3/4" | 35/64" | 1.07" | 0.08" | 50 | $26.36 | |
| DHN-1545 | 5/8"-11 | 15/16" | 43/64" | 1.33" | 0.1" | 20 | $26.36 | |
| DHN-1546 | 3/4"-10 | 1 1/8" | 13/16" | 1.585" | 0.11" | 10 | $26.36 | |
| Grade G Metric, Class 10 Zinc Yellow Chromate Flanged Hex Nuts | |||||||||
| Part # | Thread Size | Thread Pitch (mm) | Width mm | Height mm | Flange Dia. Mm | Flange Thickness mm | Pkg. Qty | Pkg. Price | |
|---|---|---|---|---|---|---|---|---|---|
| DHN-1547 | M6 | 1 | 10 | 9.1 | 14.2 | 1.1 | 50 | $22.65 | |
| DHN-1548 | M8 | 1.25 | 13 | 11 | 17.9 | 1.2 | 50 | $30.73 | |
| DHN-1549 | M10 | 1.5 | 15 | 13.5 | 21.8 | 1.5 | 25 | $22.65 | |
| DHN-1550 | M12 | 1.75 | 18 | 16.1 | 26 | 1.8 | 25 | $26.71 | |
| DHN-1551 | M14 | 2 | 21 | 18.2 | 29.9 | 2.1 | 10 | $21.86 | |
| DHN-1552 | M16 | 2 | 24 | 20.3 | 34.5 | 2.4 | 5 | $26.71 | |
| Grade F Metric, Zinc Plate Flanged Hex Nuts | ||||||||
| Part # | Thread Size | Width | Height | Flange Dia | Flange Thickness | Pkg. Qty. | Pkg. Price | |
|---|---|---|---|---|---|---|---|---|
| DHN-1553 | 6-32 | 5/16" | 13/64" | 0.422" | 0.02" | 200 | $44.93 | |
| DHN-1554 | 8-32 | 11/32" | 1/4" | 0.469" | 0.02" | 200 | $51.78 | |
| DHN-1555 | 10-24 | 3/8" | 17/64" | 0.5" | 0.03" | 200 | $54.69 | |
| DHN-1556 | 10-32 | 3/8" | 17/64" | 0.5" | 0.03" | 200 | $54.69 | |
| DHN-1557 | 1/4"-20 | 7/16" | 19/64" | 0.56" | 0.04" | 200 | $82.44 | |
| DHN-1558 | 1/4"-28 | 7/16" | 19/64" | 0.56" | 0.04" | 200 | $36.16 | |
| DHN-1559 | 5/16"-18 | 1/2" | 11/32" | 0.68" | 0.05" | 200 | $66.08 | |
| DHN-1560 | 5/16"-24 | 1/2" | 11/32" | 0.68" | 0.05" | 200 | $44.08 | |
| DHN-1561 | 3/8"-16 | 9/16" | 13/32" | 0.81" | 0.06" | 200 | $102.16 | |
| DHN-1562 | 3/8"-24 | 9/16" | 13/32" | 0.81" | 0.06" | 200 | $104.58 | |
| DHN-1563 | 7/16"-14 | 11/16" | 15/32" | 0.93" | 0.07" | 50 | $116.29 | |
| DHN-1564 | 1/2"-13 | 3/4" | 35/64" | 1.07" | 0.08" | 50 | $116.29 | |
| DHN-1565 | 1/2"-20 | 3/4" | 35/64" | 1.07" | 0.08" | 25 | $59.15 | |
| DHN-1566 | 5/8"-11 | 15/16" | 43/64" | 1.33" | 0.1" | 20 | $90.17 | |
| DHN-1567 | 3/4"-10 | 1 1/8" | 13/16" | 1.585" | 0.11" | 15 | $54.53 | |
| 18-8 Stainless Steel Flanged Hex Nuts | ||||||||
| Part # | Thread Size | Width | Height | Flange Dia | Flange Thickness | Pkg. Qty. | Pkg. Price | |
|---|---|---|---|---|---|---|---|---|
| DHN-1568 | 1/4"-20 | 7/16" | 19/64" | 0.56" | 0.04" | 50 | $39.41 | |
| DHN-1569 | 5/16"-18 | 1/2" | 11/32" | 0.68" | 0.05" | 50 | $49.19 | |
| DHN-1570 | 3/8"-16 | 9/16" | 13/32" | 0.81" | 0.06" | 25 | $29.53 | |
| 18-8 Stainless Steel Metric Flanged Hex Nuts | |||||||||
| Part # | Thread Size | Thread Pitch (mm) | Width mm | Height mm | Flange Dia. Mm | Flange Thickness mm | Pkg. Qty | Pkg. Price | |
|---|---|---|---|---|---|---|---|---|---|
| DHN-1571 | M4 | 0.7 | 7 | 6.1 | 10.2 | 1.2 | 20 | $29.76 | |
| DHN-1572 | M5 | 0.8 | 8 | 7.1 | 11.8 | 1 | 10 | $18.14 | |
| DHN-1573 | M6 | 1 | 10 | 9.1 | 14.2 | 1.1 | 10 | $21.38 | |
| DHN-1574 | M8 | 1.25 | 13 | 11.1 | 17.9 | 1.2 | 10 | $29.76 | |
| DHN-1575 | M10 | 1.5 | 15 | 13.5 | 21.8 | 1.5 | 5 | $21.38 | |
| DHN-1576 | M12 | 1.75 | 18 | 16.1 | 26 | 1.8 | 5 | $32.38 | |
