1.75" Long Spacers
| 1.75" Length Spacers | ||||||||
| Part # | Material | Screw Size | OD | OD Tol | ID | ID Tol | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|
| Spacer-476 | 18-8 Stainless Steel | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $17.77 |
| Spacer-488 | 18-8 Stainless Steel | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $17.85 |
| Spacer-500 | 18-8 Stainless Steel | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $17.77 |
| Spacer-542 | 18-8 Stainless Steel | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $15.44 |
| Spacer-1531 | 18-8 Stainless Steel | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $18.05 |
| Spacer-1571 | 18-8 Stainless Steel | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $15.23 |
| Spacer-512 | 18-8 Stainless Steel | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $17.77 |
| Spacer-572 | 18-8 Stainless Steel | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $15.44 |
| Spacer-1536 | 18-8 Stainless Steel | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $18.05 |
| Spacer-1596 | 18-8 Stainless Steel | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $15.23 |
| Spacer-602 | 18-8 Stainless Steel | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $15.44 |
| Spacer-1541 | 18-8 Stainless Steel | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $18.05 |
| Spacer-1621 | 18-8 Stainless Steel | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $15.23 |
| Spacer-1661 | 18-8 Stainless Steel | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $28.55 |
| Spacer-1546 | 18-8 Stainless Steel | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $18.05 |
| Spacer-1676 | 18-8 Stainless Steel | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $28.55 |
| Spacer-1694 | 18-8 Stainless Steel | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $36.28 |
| Spacer-1685 | 18-8 Stainless Steel | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $36.28 |
| Spacer-919 | Aluminum 2011-T3 | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $4.02 |
| Spacer-931 | Aluminum 2011-T3 | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $4.10 |
| Spacer-824 | Aluminum 2011-T3 | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $4.02 |
| Spacer-962 | Aluminum 2011-T3 | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $5.41 |
| Spacer-1867 | Aluminum 2011-T3 | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $5.89 |
| Spacer-1907 | Aluminum 2011-T3 | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $9.31 |
| Spacer-943 | Aluminum 2011-T3 | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $4.02 |
| Spacer-992 | Aluminum 2011-T3 | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $5.41 |
| Spacer-1872 | Aluminum 2011-T3 | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $5.89 |
| Spacer-1932 | Aluminum 2011-T3 | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $9.31 |
| Spacer-1022 | Aluminum 2011-T3 | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $5.41 |
| Spacer-1877 | Aluminum 2011-T3 | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $5.89 |
| Spacer-1957 | Aluminum 2011-T3 | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $9.15 |
| Spacer-1982 | Aluminum 2011-T3 | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $9.31 |
| Spacer-3078 | Aluminum 2011-T3 | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $11.98 |
| Spacer-1882 | Aluminum 2011-T3 | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $5.89 |
| Spacer-3118 | Aluminum 2011-T3 | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $11.98 |
| Spacer-2032 | Aluminum 2011-T3 | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $13.26 |
| Spacer-1427 | Nylon 6-6 Natural | 6 | .312" | +/-.015" | .140" | +/-.005" | 5 | $33.00 |
| Spacer-2292 | Nylon 6-6 Natural | 6 | .500" | +/-.015" | .140" | +/-.005" | 5 | $38.04 |
| Spacer-2897 | Nylon 6-6 Natural | 8 | .312" | +/-.015" | .166" | +/-.005" | 5 | $33.00 |
| Spacer-2258 | Nylon 6-6 Natural | 8 | .375" | +/-.015" | .166" | +/-.005" | 5 | $33.36 |
| Spacer-2316 | Nylon 6-6 Natural | 8 | .500" | +/-.015" | .166" | +/-.005" | 5 | $38.04 |
| Spacer-1450 | Nylon 6-6 Natural | 10 | .312" | +/-.015" | .192" | +/-.005" | 5 | $33.00 |
| Spacer-2263 | Nylon 6-6 Natural | 10 | .375" | +/-.015" | .192" | +/-.005" | 5 | $33.36 |
| Spacer-2340 | Nylon 6-6 Natural | 10 | .500" | +/-.015" | .192" | +/-.005" | 5 | $38.04 |
| Spacer-2268 | Nylon 6-6 Natural | 12 | .375" | +/-.015" | .218" | +/-.005" | 5 | $33.36 |
| Spacer-2364 | Nylon 6-6 Natural | 1/4" | .500" | +/-.015" | .252" | +/-.005" | 5 | $38.04 |
| Spacer-1738 | Zinc Plated Brass | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $14.84 |
| Spacer-1762 | Zinc Plated Brass | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $14.84 |
| Spacer-1786 | Zinc Plated Brass | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $15.55 |
| Spacer-1826 | Zinc Plated Brass | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $26.85 |
| Spacer-1810 | Zinc Plated Brass | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $15.55 |
| Spacer-1842 | Zinc Plated Brass | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $28.19 |
| Spacer-1862 | Zinc Plated Brass | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $36.38 |
| Spacer-1852 | Zinc Plated Brass | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $34.66 |
| Spacer-1136 | Zinc Plated Steel | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $7.82 |
| Spacer-1149 | Zinc Plated Steel | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $7.90 |
| Spacer-1162 | Zinc Plated Steel | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $7.82 |
| Spacer-1205 | Zinc Plated Steel | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $9.19 |
| Spacer-2060 | Zinc Plated Steel | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $9.19 |
| Spacer-2097 | Zinc Plated Steel | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $12.25 |
| Spacer-1175 | Zinc Plated Steel | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $8.20 |
| Spacer-1235 | Zinc Plated Steel | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $9.65 |
| Spacer-2064 | Zinc Plated Steel | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $9.65 |
| Spacer-2122 | Zinc Plated Steel | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $12.25 |
| Spacer-1265 | Zinc Plated Steel | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $9.65 |
| Spacer-2068 | Zinc Plated Steel | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $9.65 |
| Spacer-2147 | Zinc Plated Steel | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $12.84 |
| Spacer-2188 | Zinc Plated Steel | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $16.51 |
| Spacer-2072 | Zinc Plated Steel | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $9.65 |
| Spacer-2172 | Zinc Plated Steel | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $12.84 |
| Spacer-2204 | Zinc Plated Steel | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $16.51 |
| Spacer-2224 | Zinc Plated Steel | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $22.86 |
| Spacer-2214 | Zinc Plated Steel | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $22.86 |
| Screw size number | SAE diameter (inch) | Metric diameter (mm) | Screw size number | SAE diameter (inch) | Metric diameter (mm) | |
| #0 | 0.060 | 1.524 | #9 | 0.177 | 4.496 | |
| #1 | 0.073 | 1.854 | #10 | 0.190 | 4.826 | |
| #2 | 0.086 | 2.184 | #11 | 0.203 | 5.156 | |
| #3 | 0.099 | 2.515 | #12 | 0.216 | 5.486 | |
| #4 | 0.122 | 3.099 | #14 | 0.242 | 6.147 | |
| #5 | 0.125 | 3.175 | #16 | 0.268 | 6.807 | |
| #6 | 0.138 | 3.505 | #18 | 0.294 | 7.468 | |
| #7 | 0.151 | 3.835 | #20 | 0.320 | 8.128 | |
| #8 | 0.164 | 4.166 | #24 | 0.372 | 9.449 |
