.500" Long Spacers
| .500" Lengths Spacers | ||||||||
| Part # | Material | Screw Size | OD | OD Tol | ID | ID Tol | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|
| Spacer-053 | 18-8 Stainless Steel | 2 | .187" | +/-.003" | .090" | +.010"/-0 | 1 | $4.61 |
| Spacer-091 | 18-8 Stainless Steel | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $3.73 |
| Spacer-072 | 18-8 Stainless Steel | 4 | .187" | +/-.003" | .115" | +.010"/-0 | 1 | $4.69 |
| Spacer-108 | 18-8 Stainless Steel | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $3.81 |
| Spacer-125 | 18-8 Stainless Steel | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $3.73 |
| Spacer-526 | 18-8 Stainless Steel | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $6.16 |
| Spacer-617 | 18-8 Stainless Steel | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $5.83 |
| Spacer-1554 | 18-8 Stainless Steel | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $8.66 |
| Spacer-142 | 18-8 Stainless Steel | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $3.73 |
| Spacer-556 | 18-8 Stainless Steel | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $6.16 |
| Spacer-643 | 18-8 Stainless Steel | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $5.83 |
| Spacer-1579 | 18-8 Stainless Steel | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $8.66 |
| Spacer-586 | 18-8 Stainless Steel | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $6.16 |
| Spacer-669 | 18-8 Stainless Steel | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $5.83 |
| Spacer-1604 | 18-8 Stainless Steel | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $8.66 |
| Spacer-1652 | 18-8 Stainless Steel | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $17.75 |
| Spacer-695 | 18-8 Stainless Steel | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $5.83 |
| Spacer-1629 | 18-8 Stainless Steel | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $8.66 |
| Spacer-1667 | 18-8 Stainless Steel | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $17.75 |
| Spacer-1688 | 18-8 Stainless Steel | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $28.32 |
| Spacer-1679 | 18-8 Stainless Steel | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $28.32 |
| Spacer-244 | Aluminum 2011-T3 | 2 | .187" | +/-.003" | .090" | +.010"/-0 | 1 | $1.21 |
| Spacer-263 | Aluminum 2011-T3 | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $1.08 |
| Spacer-3113 | Aluminum 2011-T3 | 4 | .187" | +/-.003" | .115" | +.010"/-0 | 1 | $1.29 |
| Spacer-280 | Aluminum 2011-T3 | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $1.16 |
| Spacer-297 | Aluminum 2011-T3 | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $1.08 |
| Spacer-946 | Aluminum 2011-T3 | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $3.50 |
| Spacer-1037 | Aluminum 2011-T3 | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $3.14 |
| Spacer-1890 | Aluminum 2011-T3 | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $4.38 |
| Spacer-314 | Aluminum 2011-T3 | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $1.08 |
| Spacer-976 | Aluminum 2011-T3 | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $3.50 |
| Spacer-1062 | Aluminum 2011-T3 | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $3.14 |
| Spacer-1915 | Aluminum 2011-T3 | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $4.38 |
| Spacer-1006 | Aluminum 2011-T3 | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $3.50 |
| Spacer-1087 | Aluminum 2011-T3 | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $3.14 |
| Spacer-1940 | Aluminum 2011-T3 | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $4.38 |
| Spacer-1988 | Aluminum 2011-T3 | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $4.99 |
| Spacer-1112 | Aluminum 2011-T3 | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $3.14 |
| Spacer-2035 | Aluminum 2011-T3 | 1/2" | 1.00" | +/-.003" | .505"" | +.010"/-0 | 1 | $18.19 |
| Spacer-1965 | Aluminum 2011-T3 | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $4.38 |
| Spacer-2003 | Aluminum 2011-T3 | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $4.99 |
| Spacer-2047 | Aluminum 2011-T3 | 3/4" | 1.50" | +/-.003" | .755" | +.010"/-0 | 1 | $21.18 |
| Spacer-2025 | Aluminum 2011-T3 | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $6.04 |
| Spacer-2015 | Aluminum 2011-T3 | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $6.04 |
| Spacer-2041 | Aluminum 2011-T3 | 5/8" | 1.00" | +/-.003" | .630" | +.010"/-0 | 1 | $18.19 |
| Spacer-414 | Nylon 6-6 Natural | 2 | .187" | +/-.015" | .090" | +/-.005" | 100 | $32.81 |
| Spacer-427 | Nylon 6-6 Natural | 2 | .250" | +/-.015" | .090" | +/-.005" | 100 | $34.07 |
| Spacer-2865 | Nylon 6-6 Natural | 4 | .187" | +/-.015" | .115" | +/-.005" | 100 | $32.89 |
| Spacer-438 | Nylon 6-6 Natural | 4 | .250" | +/-.015" | .115" | +/-.005" | 100 | $34.15 |
| Spacer-450 | Nylon 6-6 Natural | 6 | .250" | +/-.015" | .140" | +/-.005" | 100 | $34.07 |
| Spacer-1412 | Nylon 6-6 Natural | 6 | .312" | +/-.015" | .140" | +/-.005" | 100 | $33.23 |
| Spacer-1458 | Nylon 6-6 Natural | 6 | .375" | +/-.015" | .140" | +/-.005" | 100 | $34.15 |
| Spacer-2275 | Nylon 6-6 Natural | 6 | .500" | +/-.015" | .140" | +/-.005" | 100 | $37.85 |
| Spacer-461 | Nylon 6-6 Natural | 8 | .250" | +/-.015" | .166" | +/-.005" | 100 | $34.07 |
| Spacer-2861 | Nylon 6-6 Natural | 8 | .312" | +/-.015" | .166" | +/-.005" | 100 | $33.23 |
| Spacer-1477 | Nylon 6-6 Natural | 8 | .375" | +/-.015" | .166" | +/-.005" | 100 | $34.15 |
| Spacer-2299 | Nylon 6-6 Natural | 8 | .500" | +/-.015" | .166" | +/-.005" | 100 | $37.85 |
| Spacer-1435 | Nylon 6-6 Natural | 10 | .312" | +/-.015" | .192" | +/-.005" | 100 | $33.23 |
| Spacer-1496 | Nylon 6-6 Natural | 10 | .375" | +/-.015" | .192" | +/-.005" | 100 | $34.15 |
| Spacer-2323 | Nylon 6-6 Natural | 10 | .500" | +/-.015" | .192" | +/-.005" | 100 | $37.85 |
| Spacer-2347 | Nylon 6-6 Natural | 1/4" | .500" | +/-.015" | .252" | +/-.005" | 100 | $37.85 |
| Spacer-159 | Zinc Plated Brass | 2 | .187" | +/-.003" | .090" | +.010"/-0 | 1 | $5.15 |
| Spacer-178 | Zinc Plated Brass | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $4.13 |
| Spacer-2988 | Zinc Plated Brass | 4 | .187" | +/-.003" | .115" | +.010"/-0 | 1 | $5.23 |
| Spacer-195 | Zinc Plated Brass | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $4.21 |
| Spacer-211 | Zinc Plated Brass | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $4.13 |
| Spacer-771 | Zinc Plated Brass | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $5.41 |
| Spacer-802 | Zinc Plated Brass | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $6.14 |
| Spacer-1722 | Zinc Plated Brass | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $9.25 |
| Spacer-228 | Zinc Plated Brass | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $4.13 |
| Spacer-2921 | Zinc Plated Brass | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $5.41 |
| Spacer-849 | Zinc Plated Brass | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $6.14 |
| Spacer-1746 | Zinc Plated Brass | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $9.25 |
| Spacer-2923 | Zinc Plated Brass | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $5.41 |
| Spacer-873 | Zinc Plated Brass | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $6.14 |
| Spacer-1770 | Zinc Plated Brass | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $9.25 |
| Spacer-1816 | Zinc Plated Brass | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $15.05 |
| Spacer-897 | Zinc Plated Brass | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $6.14 |
| Spacer-1794 | Zinc Plated Brass | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $9.25 |
| Spacer-1832 | Zinc Plated Brass | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $15.05 |
| Spacer-1855 | Zinc Plated Brass | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $19.66 |
| Spacer-1845 | Zinc Plated Brass | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $19.66 |
| Spacer-331 | Zinc Plated Steel | 2 | .187" | +/-.003" | .090" | +.010"/-0 | 1 | $4.82 |
| Spacer-351 | Zinc Plated Steel | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $4.99 |
| Spacer-2937 | Zinc Plated Steel | 4 | .187" | +/-.003" | .115" | +.010"/-0 | 1 | $4.90 |
| Spacer-386 | Zinc Plated Steel | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $5.07 |
| Spacer-368 | Zinc Plated Steel | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $4.99 |
| Spacer-1189 | Zinc Plated Steel | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $5.15 |
| Spacer-1278 | Zinc Plated Steel | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $5.15 |
| Spacer-2080 | Zinc Plated Steel | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $6.90 |
| Spacer-403 | Zinc Plated Steel | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $4.99 |
| Spacer-1219 | Zinc Plated Steel | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $5.15 |
| Spacer-1300 | Zinc Plated Steel | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $5.15 |
| Spacer-2105 | Zinc Plated Steel | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $6.90 |
| Spacer-1249 | Zinc Plated Steel | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $5.15 |
| Spacer-1322 | Zinc Plated Steel | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $5.15 |
| Spacer-2130 | Zinc Plated Steel | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $6.90 |
| Spacer-2178 | Zinc Plated Steel | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $6.86 |
| Spacer-1344 | Zinc Plated Steel | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $5.15 |
| Spacer-2227 | Zinc Plated Steel | 1/2" | 1.00" | +/-.003" | .505"" | +.010"/-0 | 1 | $36.91 |
| Spacer-2155 | Zinc Plated Steel | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $6.90 |
| Spacer-2194 | Zinc Plated Steel | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $6.86 |
| Spacer-2239 | Zinc Plated Steel | 3/4" | 1.50" | +/-.003" | .755" | +.010"/-0 | 1 | $35.46 |
| Spacer-2217 | Zinc Plated Steel | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $8.67 |
| Spacer-2207 | Zinc Plated Steel | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $8.75 |
| Spacer-2233 | Zinc Plated Steel | 5/8" | 1.00" | +/-.003" | .630" | +.010"/-0 | 1 | $29.96 |
| Screw size number | SAE diameter (inch) | Metric diameter (mm) | Screw size number | SAE diameter (inch) | Metric diameter (mm) | |
| #0 | 0.060 | 1.524 | #9 | 0.177 | 4.496 | |
| #1 | 0.073 | 1.854 | #10 | 0.190 | 4.826 | |
| #2 | 0.086 | 2.184 | #11 | 0.203 | 5.156 | |
| #3 | 0.099 | 2.515 | #12 | 0.216 | 5.486 | |
| #4 | 0.122 | 3.099 | #14 | 0.242 | 6.147 | |
| #5 | 0.125 | 3.175 | #16 | 0.268 | 6.807 | |
| #6 | 0.138 | 3.505 | #18 | 0.294 | 7.468 | |
| #7 | 0.151 | 3.835 | #20 | 0.320 | 8.128 | |
| #8 | 0.164 | 4.166 | #24 | 0.372 | 9.449 |
