1/2" Screw Size Spacers
1/2" Screw Size Spacers |
||||||
| Part # | Material | OD | ID | Length | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| Spacer-2034 | Aluminum 2011-T3 | 1.00" | .505" | .375" | 1 | $18.27 |
| Spacer-2035 | Aluminum 2011-T3 | 1.00" | .505" | .500" | 1 | $18.27 |
| Spacer-2036 | Aluminum 2011-T3 | 1.00" | .505" | .750" | 1 | $20.27 |
| Spacer-2037 | Aluminum 2011-T3 | 1.00" | .505" | 1.00" | 1 | $21.26 |
| Spacer-2038 | Aluminum 2011-T3 | 1.00" | .505" | 1.50" | 1 | $31.74 |
| Spacer-2039 | Aluminum 2011-T3 | 1.00" | .505" | 2.00" | 1 | $31.74 |
| Spacer-2226 | Zinc Plated Steel | 1.00" | .505" | .375" | 1 | $30.03 |
| Spacer-2227 | Zinc Plated Steel | 1.00" | .505" | .500" | 1 | $36.99 |
| Spacer-2228 | Zinc Plated Steel | 1.00" | .505" | .750" | 1 | $34.30 |
| Spacer-2229 | Zinc Plated Steel | 1.00" | .505" | 1.00" | 1 | $36.99 |
| Spacer-2230 | Zinc Plated Steel | 1.00" | .505" | 1.50" | 1 | $41.42 |
| Spacer-2231 | Zinc Plated Steel | 1.00" | .505" | 2.00" | 1 | $46.94 |
| Screw size number | SAE diameter (inch) | Metric diameter (mm) | Screw size number | SAE diameter (inch) | Metric diameter (mm) | |
| #0 | 0.060 | 1.524 | #9 | 0.177 | 4.496 | |
| #1 | 0.073 | 1.854 | #10 | 0.190 | 4.826 | |
| #2 | 0.086 | 2.184 | #11 | 0.203 | 5.156 | |
| #3 | 0.099 | 2.515 | #12 | 0.216 | 5.486 | |
| #4 | 0.122 | 3.099 | #14 | 0.242 | 6.147 | |
| #5 | 0.125 | 3.175 | #16 | 0.268 | 6.807 | |
| #6 | 0.138 | 3.505 | #18 | 0.294 | 7.468 | |
| #7 | 0.151 | 3.835 | #20 | 0.320 | 8.128 | |
| #8 | 0.164 | 4.166 | #24 | 0.372 | 9.449 |
