3/8" Screw Size Spacers
| 3/8" Screw Size Standoffs / Spacers | ||||||
| OD Tol. +/- .003", ID Tol. +.010"/- 0 | ||||||
| Part # | Material | OD | ID | Length | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| Spacer-1687 | 18-8 Stainless Steel | .750" | .380" | .375" | 1 | $28.46 |
| Spacer-1688 | 18-8 Stainless Steel | .750" | .380" | .500" | 1 | $28.48 |
| Spacer-1689 | 18-8 Stainless Steel | .750" | .380" | .625" | 1 | $28.31 |
| Spacer-1690 | 18-8 Stainless Steel | .750" | .380" | .750" | 1 | $28.31 |
| Spacer-1691 | 18-8 Stainless Steel | .750" | .380" | .875" | 1 | $31.08 |
| Spacer-1692 | 18-8 Stainless Steel | .750" | .380" | 1.25" | 1 | $31.23 |
| Spacer-1693 | 18-8 Stainless Steel | .750" | .380" | 1.50" | 1 | $36.10 |
| Spacer-1694 | 18-8 Stainless Steel | .750" | .380" | 1.75" | 1 | $36.44 |
| Spacer-1695 | 18-8 Stainless Steel | .750" | .380" | 2.00" | 1 | $40.59 |
| Spacer-2024 | Aluminum 2011-T3 | .750" | .380" | .375" | 1 | $6.20 |
| Spacer-2025 | Aluminum 2011-T3 | .750" | .380" | .500" | 1 | $6.20 |
| Spacer-2026 | Aluminum 2011-T3 | .750" | .380" | .625" | 1 | $6.15 |
| Spacer-2027 | Aluminum 2011-T3 | .750" | .380" | .750" | 1 | $7.27 |
| Spacer-2028 | Aluminum 2011-T3 | .750" | .380" | .875" | 1 | $7.06 |
| Spacer-2029 | Aluminum 2011-T3 | .750" | .380" | 1.00" | 1 | $7.60 |
| Spacer-2032 | Aluminum 2011-T3 | .750" | .380" | 1.75" | 1 | $13.42 |
| Spacer-2033 | Aluminum 2011-T3 | .750" | .380" | 2.00" | 1 | $13.42 |
| Spacer-1854 | Zinc Plated Brass | .750" | .380" | .375" | 1 | $16.74 |
| Spacer-1855 | Zinc Plated Brass | .750" | .380" | .500" | 1 | $19.82 |
| Spacer-1856 | Zinc Plated Brass | .750" | .380" | .625" | 1 | $21.84 |
| Spacer-1857 | Zinc Plated Brass | .750" | .380" | .750" | 1 | $24.15 |
| Spacer-1858 | Zinc Plated Brass | .750" | .380" | .875" | 1 | $22.95 |
| Spacer-3073 | Zinc Plated Brass | .750" | .380" | 1.00" | 1 | $28.25 |
| Spacer-1860 | Zinc Plated Brass | .750" | .380" | 1.25" | 1 | $30.85 |
| Spacer-1861 | Zinc Plated Brass | .750" | .380" | 1.50" | 1 | $31.35 |
| Spacer-1862 | Zinc Plated Brass | .750" | .380" | 1.75" | 1 | $36.54 |
| Spacer-1863 | Zinc Plated Brass | .750" | .380" | 2.00" | 1 | $37.28 |
| Spacer-2216 | Zinc Plated Steel | .750" | .380" | .375" | 1 | $7.25 |
| Spacer-2217 | Zinc Plated Steel | .750" | .380" | .500" | 1 | $8.83 |
| Spacer-2218 | Zinc Plated Steel | .750" | .380" | .625" | 1 | $10.10 |
| Spacer-2219 | Zinc Plated Steel | .750" | .380" | .750" | 1 | $12.08 |
| Spacer-2220 | Zinc Plated Steel | .750" | .380" | .875" | 1 | $12.45 |
| Spacer-2221 | Zinc Plated Steel | .750" | .380" | 1.00" | 1 | $14.20 |
| Spacer-2222 | Zinc Plated Steel | .750" | .380" | 1.25" | 1 | $15.98 |
| Spacer-2223 | Zinc Plated Steel | .750" | .380" | 1.50" | 1 | $19.30 |
| Spacer-2224 | Zinc Plated Steel | .750" | .380" | 1.75" | 1 | $23.02 |
| Spacer-2225 | Zinc Plated Steel | .750" | .380" | 2.00" | 1 | $28.46 |
| Screw size number | SAE diameter (inch) | Metric diameter (mm) | Screw size number | SAE diameter (inch) | Metric diameter (mm) | |
| #0 | 0.060 | 1.524 | #9 | 0.177 | 4.496 | |
| #1 | 0.073 | 1.854 | #10 | 0.190 | 4.826 | |
| #2 | 0.086 | 2.184 | #11 | 0.203 | 5.156 | |
| #3 | 0.099 | 2.515 | #12 | 0.216 | 5.486 | |
| #4 | 0.122 | 3.099 | #14 | 0.242 | 6.147 | |
| #5 | 0.125 | 3.175 | #16 | 0.268 | 6.807 | |
| #6 | 0.138 | 3.505 | #18 | 0.294 | 7.468 | |
| #7 | 0.151 | 3.835 | #20 | 0.320 | 8.128 | |
| #8 | 0.164 | 4.166 | #24 | 0.372 | 9.449 |
