18-8 Stainless Steel Taper Pins
| Taper Pins 18-8 Stainless Steel, Chamfered Ends | ||||||
| Diameter Tolerance +.0013"/-.0007" | ||||||
| Part # | Taper Pin Size | Major Diameter | Small End Diameter | Length | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| DMTP-244 | 0 | .156" | .094" | 3.00" | 10 | $27.52 |
| DMTP-245 | 0 | .156" | 0.114 | 2.00" | 10 | $20.04 |
| DMTP-111 | 0 | .156" | .125" | 1.50" | 100 | $136.84 |
| DMTP-110 | 0 | .156" | .130" | 1.25" | 100 | $120.08 |
| DMTP-109 | 0 | .156" | .135" | 1.00" | 100 | $102.90 |
| DMTP-108 | 0 | .156" | .140" | .750" | 100 | $81.28 |
| DMTP-224 | 1 | .172" | .089" | 4.00" | 5 | $22.78 |
| DMTP-115 | 1 | .172" | .110" | 3.00" | 100 | $252.10 |
| DMTP-114 | 1 | .172" | .130" | 2.00" | 100 | $188.62 |
| DMTP-113 | 1 | .172" | .141" | 1.50" | 100 | $150.84 |
| DMTP-223 | 1 | .172" | .146" | 1.25" | 20 | $28.52 |
| DMTP-222 | 1 | .172" | .151" | 1.00" | 20 | $24.40 |
| DMTP-112 | 1 | .172" | .156" | .750" | 100 | $89.94 |
| DMTP-217 | 2 | .193" | .110" | 4.00" | 5 | $26.90 |
| DMTP-121 | 2 | .193" | .131" | 3.00" | 100 | $252.76 |
| DMTP-120 | 2 | .193" | .140" | 2.50" | 100 | $238.98 |
| DMTP-119 | 2 | .193" | .151" | 2.00" | 100 | $199.78 |
| DMTP-118 | 2 | .193" | .162" | 1.50" | 100 | $162.38 |
| DMTP-117 | 2 | .193" | .167" | 1.25" | 100 | $136.44 |
| DMTP-116 | 2 | .193" | .172" | 1.00" | 100 | $125.34 |
| DMTP-227 | 2 | .193" | .177" | .750" | 20 | $22.88 |
| DMTP-246 | 2/0 | .141" | .089" | 2.50" | 10 | $21.54 |
| DMTP-247 | 2/0 | .141" | .099" | 2.00" | 20 | $35.12 |
| DMTP-248 | 2/0 | .141" | .110" | 1.50" | 20 | $28.16 |
| DMTP-261 | 2/0 | .141" | .115" | 1.25" | 20 | $25.80 |
| DMTP-107 | 2/0 | .141" | .120" | 1.00" | 100 | $102.90 |
| DMTP-106 | 2/0 | .141" | .125" | .750" | 100 | $81.28 |
| DMTP-231 | 3 | .219" | .136" | 4.00" | 5 | $28.80 |
| DMTP-128 | 3 | .219" | .157" | 3.00" | 25 | $82.50 |
| DMTP-127 | 3 | .219" | .167" | 2.50" | 25 | $68.50 |
| DMTP-126 | 3 | .219" | .177" | 2.00" | 25 | $50.50 |
| DMTP-269 | 3 | .219" | .183" | 1.75" | 10 | $20.94 |
| DMTP-125 | 3 | .219" | .188" | 1.50" | 100 | $174.56 |
| DMTP-124 | 3 | .219" | .193" | 1.25" | 100 | $136.84 |
| DMTP-123 | 3 | .219" | .198" | 1.00" | 100 | $136.84 |
| DMTP-122 | 3 | .219" | .203" | .750" | 100 | $118.28 |
| DMTP-259 | 3/0 | .125" | .094" | 1.50" | 20 | $29.52 |
| DMTP-105 | 3/0 | .125" | .099" | 1.25" | 100 | $160.08 |
| DMTP-104 | 3/0 | .125" | .104" | 1.00" | 100 | $102.90 |
| DMTP-228 | 3/0 | .125" | .109" | .750" | 25 | $23.08 |
| DMTP-251 | 3/0 | .125" | .115" | .500" | 25 | $23.08 |
| DMTP-303 | 4 | .250" | .156" | 4.50" | 3 | $23.22 |
| DMTP-135 | 4 | .250" | .167" | 4.00" | 25 | $135.00 |
| DMTP-134 | 4 | .250" | .188" | 3.00" | 25 | $95.00 |
| DMTP-302 | 4 | .250" | .193" | 2.75" | 10 | $26.40 |
| DMTP-133 | 4 | .250" | .198" | 2.50" | 25 | $71.50 |
| DMTP-301 | 4 | .250" | .203" | 2.25" | 10 | $26.40 |
| DMTP-300 | 4 | .250" | .208" | 2.00" | 10 | $24.22 |
| DMTP-299 | 4 | .250" | .214" | 1.75" | 10 | $22.20 |
| DMTP-132 | 4 | .250" | .219" | 1.50" | 25 | $43.00 |
| DMTP-131 | 4 | .250" | .224" | 1.25" | 25 | $37.00 |
| DMTP-129 | 4 | .250" | .234" | .750" | 25 | $33.50 |
| DMTP-249 | 4/0 | .109" | .078" | 1.50" | 20 | $29.52 |
| DMTP-102 | 4/0 | .109" | .082" | 1.25" | 100 | $120.08 |
| DMTP-101 | 4/0 | .109" | .088" | 1.00" | 100 | $102.90 |
| DMTP-100 | 4/0 | .109" | .093" | .750" | 100 | $81.28 |
| DMTP-218 | 4/0 | .109" | .099" | .500" | 25 | $23.08 |
| DMTP-103 | 4/0 | .125" | .114" | .500" | 100 | $81.28 |
| DMTP-264 | 5 | .289" | .143" | 7.00" | 2 | $27.22 |
| DMTP-296 | 5 | .289" | .164" | 6.00" | 2 | $22.28 |
| DMTP-272 | 5 | .289" | .185" | 5.00" | 3 | $27.18 |
| DMTP-142 | 5 | .289" | .206" | 4.00" | 25 | $169.50 |
| DMTP-274 | 5 | .289" | .216" | 3.50" | 5 | $29.90 |
| DMTP-141 | 5 | .289" | .227" | 3.00" | 25 | $110.00 |
| DMTP-140 | 5 | .289" | .237" | 2.50" | 25 | $87.00 |
| DMTP-306 | 5 | .289" | .242" | 2.25" | 10 | $34.56 |
| DMTP-139 | 5 | .289" | .247" | 2.00" | 25 | $66.50 |
| DMTP-305 | 5 | .289" | .253" | 1.75" | 10 | $27.24 |
| DMTP-138 | 5 | .289" | .258" | 1.50" | 25 | $59.50 |
| DMTP-137 | 5 | .289" | .262" | 1.25" | 25 | $51.50 |
| DMTP-136 | 5 | .289" | .268" | 1.00" | 1 | $43.00 |
| DMTP-219 | 5/0 | .094" | .063" | 1.50" | 20 | $29.52 |
| DMTP-098 | 5/0 | .094" | .073" | 1.00" | 100 | $102.90 |
| DMTP-220 | 5/0 | .094" | .081" | .625" | 25 | $23.08 |
| DMTP-221 | 5/0 | .094" | .084" | .500" | 25 | $23.08 |
| DMTP-099 | 5/0 | .109" | .098" | .500" | 100 | $81.28 |
| DMTP-287 | 6 | .341" | .216" | 6.00" | 2 | $24.32 |
| DMTP-286 | 6 | .341" | .237" | 5.00" | 3 | $29.88 |
| DMTP-267 | 6 | .341" | .247" | 4.50" | 3 | $26.64 |
| DMTP-148 | 6 | .341" | .258" | 4.00" | 25 | $172.50 |
| DMTP-226 | 6 | .341" | .268" | 3.50" | 4 | $26.40 |
| DMTP-237 | 6 | .341" | .273" | 3.25" | 4 | $24.16 |
| DMTP-147 | 6 | .341" | .279" | 3.00" | 25 | $127.00 |
| DMTP-236 | 6 | .341" | .284" | 2.75" | 5 | $26.40 |
| DMTP-235 | 6 | .341" | .289" | 2.50" | 5 | $24.50 |
| DMTP-146 | 6 | .341" | .294" | .294" | 5 | $22.32 |
| DMTP-146 | 6 | .341" | .299" | 2.00" | 25 | $90.50 |
| DMTP-270 | 6 | .341" | .305" | 1.75" | 5 | $17.92 |
| DMTP-145 | 6 | .341" | .310" | 1.50" | 25 | $74.00 |
| DMTP-144 | 6 | .341" | .314" | 1.25" | 25 | $62.50 |
| DMTP-143 | 6 | .341" | .320" | 1.00" | 25 | $52.00 |
| DMTP-096 | 6/0 | .078" | .057" | 1.00" | 100 | $102.90 |
| DMTP-095 | 6/0 | .078" | .062" | .750" | 100 | $86.06 |
| DMTP-094 | 6/0 | .078" | .068" | .500" | 100 | $81.28 |
| DMTP-097 | 6/0 | .094" | .083" | .500" | 100 | $81.28 |
| DMTP-156 | 7 | .409" | .284" | 6.00" | 5 | $78.20 |
| DMTP-155 | 7 | .409" | .305" | 5.00" | 5 | $65.90 |
| DMTP-295 | 7 | .409" | .315" | 4.50" | 2 | $24.76 |
| DMTP-154 | 7 | .409" | .326" | 4.00" | 10 | $100.80 |
| DMTP-294 | 7 | .409" | .336" | 3.50" | 3 | $29.70 |
| DMTP-292 | 7 | .409" | .341" | 3.25" | 3 | $27.90 |
| DMTP-153 | 7 | .409" | .347" | 3.00" | 3 | $23.40 |
| DMTP-291 | 7 | .409" | .352" | 2.75" | 3 | $24.72 |
| DMTP-152 | 7 | .409" | .357" | 2.50" | 25 | $163.00 |
| DMTP-290 | 7 | .409" | .362" | 2.25" | 5 | $32.10 |
| DMTP-151 | 7 | .409" | .367" | 2.00" | 25 | $124.50 |
| DMTP-150 | 7 | .409" | .373" | 1.75" | 25 | $106.50 |
| DMTP-149 | 7 | .409" | .377" | 1.50" | 25 | $88.00 |
| DMTP-234 | 7/0 | .063" | .047" | .750" | 25 | $23.06 |
| DMTP-242 | 7/0 | .063" | .052" | .500" | 25 | $23.06 |
| DMTP-277 | 8 | .492" | .346" | 7.00" | 1 | $25.30 |
| DMTP-163 | 8 | .492" | .367" | 6.00" | 25 | $501.50 |
| DMTP-276 | 8 | .492" | .378" | 5.50" | 1 | $20.46 |
| DMTP-275 | 8 | .492" | .388" | 5.00" | 2 | $37.36 |
| DMTP-262 | 8 | .492" | .398" | 4.50" | 2 | $34.16 |
| DMTP-161 | 8 | .492" | .409" | 4.00" | 5 | $73.40 |
| DMTP-162 | 8 | .492" | .409" | 4.00" | 5 | $90.30 |
| DMTP-160 | 8 | .492" | .419" | 3.50" | 10 | $121.20 |
| DMTP-159 | 8 | .492" | .430" | 3.00" | 10 | $102.40 |
| DMTP-273 | 8 | .492" | .435" | 2.75" | 3 | $29.40 |
| DMTP-158 | 8 | .492" | .440" | 2.50" | 10 | $87.00 |
| DMTP-157 | 8 | .492" | .450" | 2.00" | 25 | $178.00 |
| DMTP-284 | 8 | .492" | .461" | 1.50" | 5 | $29.30 |
| DMTP-268 | 9 | .591" | .445" | 7.00" | 1 | $32.92 |
| DMTP-167 | 9 | .591" | .466" | 6.00" | 25 | $697.00 |
| DMTP-263 | 9 | .591" | .477" | 5.50" | 1 | $26.90 |
| DMTP-283 | 9 | .591" | .487" | 5.00" | 1 | $24.98 |
| DMTP-282 | 9 | .591" | .497" | 4.50" | 1 | $23.06 |
| DMTP-166 | 9 | .591" | .508" | 4.00" | 25 | $511.00 |
| DMTP-165 | 9 | .591" | .518" | 3.50" | 5 | $88.00 |
| DMTP-164 | 9 | .591" | .529" | 3.00" | 5 | $75.80 |
| DMTP-281 | 9 | .591" | .539" | 2.50" | 2 | $27.20 |
| DMTP-280 | 9 | .591" | .549" | 2.00" | 2 | $23.52 |
| DMTP-297 | 10 | .706" | .560" | 7.00" | 1 | $43.96 |
| DMTP-172 | 10 | .706" | .581" | 6.00" | 25 | $912.50 |
| DMTP-171 | 10 | .706" | .602" | 5.00" | 25 | $812.50 |
| DMTP-307 | 10 | .706" | .612" | 4.50" | 1 | $29.80 |
| DMTP-170 | 10 | .706" | .623" | 4.00" | 25 | $640.00 |
| DMTP-169 | 10 | .706" | .633" | 3.50" | 25 | $599.50 |
| DMTP-168 | 10 | .706" | .644" | 3.00" | 25 | $506.00 |
| DMTP-230 | 10 | .706" | .664" | 2.00" | 2 | $29.96 |
