PTFE Tape
3" Cardboard Spool
Acrylic Adhesive 0° to +120°F White
Silicone Adhesive -100° to +500°F
.0035" Thickness Tapes - Dielectric Strength 9000 V/m
.0045" Thickness Tapes - Dielectric Strength 11000 V/m
.0115" Thickness Tapes - Dielectric Strength 18000 V/m
.022" Thickness Tapes - Dielectric Strength 16000 V/m
.032" Thickness Tapes - Dielectric Strength 19500 V/m
.060" Thickness Tapes - Dielectric Strength 33000 V/m
| PTFE Masking Tapes | ||||||
| High Performance Electrical Insulation Silicone Adhesive | ||||||
| Part # | Tape Width | Adhesive Thickness | Total Overall Thickness | Length | Rolls/Pkg | Pkg. Price |
|---|---|---|---|---|---|---|
| TAPE-946 | .250" | .0015" | .0035" | 15' | 3 | $19.03 |
| TAPE-947 | .250" | .0015" | .0035" | 54' | 2 | $37.98 |
| TAPE-948 | .250" | .0015" | .0045" | 15' | 3 | $16.38 |
| TAPE-949 | .250" | .0015" | .0045" | 54' | 1 | $43.28 |
| TAPE-951 | .250" | .0015" | .0115" | 15' | 2 | $34.88 |
| TAPE-950 | .250" | .0015" | .0115" | 54' | 1 | $108.08 |
| TAPE-964 | .500" | .0015" | .0035" | 15' | 2 | $27.53 |
| TAPE-963 | .500" | .0015" | .0035" | 54' | 1 | $69.03 |
| TAPE-968 | .500" | .0015" | .0045" | 15' | 2 | $30.68 |
| TAPE-966 | .500" | .0015" | .0045" | 54' | 1 | $78.63 |
| TAPE-972 | .500" | .0015" | .0115" | 15' | 1 | $63.38 |
| TAPE-974 | .500" | .0015" | .0115" | 54' | 1 | $196.93 |
| TAPE-1006 | .750" | .0015" | .0035" | 15' | 2 | $39.63 |
| TAPE-1005 | .750" | .0015" | .0035" | 54' | 1 | $103.33 |
| TAPE-1010 | .750" | .0015" | .0045" | 15' | 1 | $43.83 |
| TAPE-1008 | .750" | .0015" | .0045" | 54' | 1 | $117.73 |
| TAPE-1014 | .750" | .0015" | .0115" | 15' | 1 | $95.08 |
| TAPE-1016 | .750" | .0015" | .0115" | 54' | 1 | $295.33 |
| TAPE-1040 | 1.00" | .0015" | .0035" | 15' | 1 | $52.43 |
| TAPE-1041 | 1.00" | .0015" | .0035" | 54' | 1 | $137.73 |
| TAPE-1042 | 1.00" | .0015" | .0045" | 15' | 1 | $58.43 |
| TAPE-1044 | 1.00" | .0015" | .0045" | 54' | 1 | $156.93 |
| TAPE-1050 | 1.00" | .0015" | .0115" | 15' | 1 | $126.58 |
| TAPE-1052 | 1.00" | .0015" | .0115" | 54' | 1 | $393.73 |
| TAPE-1110 | 2.00" | .0015" | .0035" | 15' | 1 | $104.78 |
| TAPE-1111 | 2.00" | .0015" | .0035" | 54' | 1 | $275.48 |
| TAPE-1113 | 2.00" | .0015" | .0045" | 15' | 1 | $112.68 |
| TAPE-1116 | 2.00" | .0015" | .0045" | 54' | 1 | $313.78 |
| TAPE-1122 | 2.00" | .0015" | .0115" | 15' | 1 | $244.08 |
| TAPE-1120 | 2.00" | .0015" | .0115" | 54' | 1 | $787.43 |
| TAPE-1150 | 3.00" | .0015" | .0035" | 15' | 1 | $155.43 |
| TAPE-1151 | 3.00" | .0015" | .0035" | 54' | 1 | $413.03 |
| TAPE-1152 | 3.00" | .0015" | .0115" | 15' | 1 | $327.86 |
| TAPE-1174 | 4.00" | .0015" | .0035" | 15' | 1 | $199.38 |
| TAPE-1173 | 4.00" | .0015" | .0035" | 54' | 1 | $550.88 |
| TAPE-1197 | 6.00" | .0015" | .0035" | 15' | 1 | $266.63 |
| TAPE-1196 | 6.00" | .0015" | .0035" | 54' | 1 | $729.78 |
| High Performance Electrical Insulation Acrylic Adhesive | ||||||
| TAPE-1034 | 1.00" | .002" | .022" | 15' | 1 | $131.04 |
| TAPE-1036 | 1.00" | .002" | .032" | 15' | 1 | $137.78 |
| TAPE-1038 | 1.00" | .002" | .062" | 15' | 1 | $227.88 |
| TAPE-1104 | 2.00" | .002" | .022" | 15' | 1 | $261.92 |
| TAPE-1106 | 2.00" | .002" | .032" | 15' | 1 | $270.68 |
| TAPE-1108 | 2.00" | .002" | .062" | 15' | 1 | $455.76 |
| TAPE-1191 | 6.00" | .002" | .022" | 15' | 1 | $785.92 |
| TAPE-1193 | 6.00" | .002" | .032" | 15' | 1 | $811.88 |
| TAPE-1195 | 6.00" | .002" | .062" | 15' | 1 | $2,050.34 |
