UHMW Tape
Higher Abrasion and Impact Strength than PTFE
FDA Compliant for Food Contact
Polyethylene Peel Off Liner
Non Stick Surface
Low Friction
Translucent Tint
Temp Ranges:
.0045", .0065". & .0115: Thick -40°F to 230°F
.0215" and .0325" 0° to 120°F
| Total Thickness | Adhesion Oz/In | Break Strength PSI | Elongation % |
| .0045" | 50 | 3000 | 125 |
| .0065" | 50 | 3000 | 125 |
| .0115" | 50 | 3000 | 125 |
| .0215" | 50 | 3000 | 125 |
| .0325" | 50 | 7740 | 460 |
| .0625" | 50 | 7056 | 463 |
| .092" | 50 | 6373 | 463 |
| .127" | 50 | 6373 | 466 |
| Abrasion Resistant UHMW Tapes Acrylic Adhesive, Translucent Minimums Apply |
||||
| Part # | Tape Width | Total Overall Thickness | Length | Price |
|---|---|---|---|---|
| TAPE-1469 | .500" | .0045" | 54' | $18.66 |
| TAPE-1471 | .500" | .0065" | 54' | $203.61 |
| TAPE-1472 | .500" | .0115" | 54' | $39.70 |
| TAPE-1485 | .500" | .0215" | 54' | $60.18 |
| TAPE-1497 | .750" | .0045" | 54' | $28.78 |
| TAPE-1498 | .750" | .0065" | 54' | $42.22 |
| TAPE-1500 | .750" | .0115" | 54' | $59.65 |
| TAPE-1511 | .750" | .0215" | 54' | $90.17 |
| TAPE-1522 | 1.00" | .0045" | 54' | $38.27 |
| TAPE-1524 | 1.00" | .0065" | 54' | $56.33 |
| TAPE-1526 | 1.00" | .0115" | 54' | $79.60 |
| TAPE-1545 | 1.00" | .0215" | 54' | $120.25 |
| TAPE-1548 | 1.00" | .0325" | 50' | $134.11 |
| TAPE-1549 | 1.00" | .0615" | 50' | $155.94 |
| TAPE-1550 | 1.00" | .092" | 50' | $204.29 |
| TAPE-1551 | 1.00" | .127" | 50' | $258.02 |
| TAPE-1577 | 2.00" | .0045" | 54' | $76.59 |
| TAPE-1580 | 2.00" | .0065" | 54' | $112.15 |
| TAPE-1582 | 2.00" | .0115" | 54' | $158.91 |
| TAPE-1598 | 2.00" | .022" | 54' | $240.34 |
| TAPE-1584 | 2.00" | .032" | 15' | $268.08 |
| TAPE-1601 | 2.00" | .032" | 50' | $268.08 |
| TAPE-1585 | 2.00" | .0615" | 15' | $162.59 |
| TAPE-1602 | 2.00" | .0615" | 50' | $311.77 |
| TAPE-1603 | 2.00" | .092" | 50' | $408.52 |
| TAPE-1604 | 2.00" | .127" | 50' | $516.03 |
| TAPE-1609 | 3.00" | .0045" | 15' | $39.70 |
| TAPE-1610 | 3.00" | .0045" | 54' | $114.81 |
| TAPE-1611 | 3.00" | .0065" | 15' | $58.08 |
| TAPE-1612 | 3.00" | .0065" | 54' | $168.54 |
| TAPE-1613 | 3.00" | .0115" | 15' | $84.50 |
| TAPE-1614 | 3.00" | .0115" | 54' | $238.33 |
| TAPE-1625 | 3.00" | .022" | 54' | $360.44 |
| TAPE-1628 | 3.00" | .032" | 50' | $402.07 |
| TAPE-1629 | 3.00" | .062" | 50' | $467.63 |
| TAPE-1630 | 3.00" | .092" | 50' | $612.71 |
| TAPE-1631 | 3.00" | .127" | 50' | $773.97 |
| TAPE-1636 | 4.00" | .062" | 50' | $623.49 |
| TAPE-1637 | 4.00" | .092" | 50' | $816.92 |
| TAPE-1638 | 4.00" | .127" | 50' | $1,031.86 |
| TAPE-1643 | 6.00" | .0045" | 15' | $79.25 |
| TAPE-1644 | 6.00" | .0045" | 54' | $229.54 |
| TAPE-1645 | 6.00" | .0065" | 15' | $114.53 |
| TAPE-1646 | 6.00" | .0065" | 54' | $337.03 |
| TAPE-1648 | 6.00" | .0115" | 15' | $161.19 |
| TAPE-1647 | 6.00" | .0115" | 54' | $476.88 |
| TAPE-1649 | 6.00" | .0215" | 15' | $253.48 |
| TAPE-1650 | 6.00" | .0325" | 15' | $804.28 |
| TAPE-1651 | 6.00" | .0615" | 15' | $487.59 |
| TAPE-1560 | 12.00" | .0045" | 15' | $160.87 |
| TAPE-1559 | 12.00" | .0045" | 54' | $413.53 |
| TAPE-1562 | 12.00" | .0065" | 15' | $203.61 |
| TAPE-1561 | 12.00" | .0065" | 54' | $539.29 |
| TAPE-1564 | 12.00" | .0115" | 15' | $260.13 |
| TAPE-1563 | 12.00" | .0115" | 54' | $731.90 |
